Description

Variable sensitivity selector

Specifications
NO. OF CHANNELS 2
OUTPUT POWER PER CHANNEL

8: 300W
4: 450W
8 BRIDGED: 1000W

THD AT RATED POWER <1%
DAMPING FACTOR >300
SIGNAL TO NOISE RATIO (20HZ ~ 20KHZ) 100dB
OUTPUT CIRCUITRY

AB
FREQUENCY RESPONSE
20Hz~20kHz, 0.5dB

INPUT CONNECTORS EACH CHANNEL XLR with link
OUTPUT CONNECTORS EACH CHANNEL
Twist-lock connector and binding post

AMPLIFIER AND LOAD PROTECTION
Short circuit, output DC, thermal, RF protection

FRONT PANEL CONTROLS AND INDICATORS

Clip, Protect and Signal LED indicators, 42 detent rotary vol control

REAR PANEL CONTROLS

3 position Slide switch for Mode – Dual, Mono, Bridge. 3 position Slide switch for Sensitivity 0.775V, 1 V and 1.4V.
INPUT POWER
(AS PER BIS IS616:2017 IEC60065:2014/IEC62368-1

600W

DIMENSIONS (WXHXD) MM
483 x 462 x 88

NET WEIGHT 17kg
AGENCY APPROVALS
CE, BIS IS616:2017

NOTE: Due to continuous improvements, all specifications are subject to change

SLA 3004

2 channel power amplifier

SLA 3004 is a 2 channel, Class AB amplifier that delivers 600 watt / channel at 4 Ohm. Detailed specifications are given below

Highlights

• Soft start
• High SNR
• Low THD, IMD
• Heavy-duty power supply for high dynamic power
• Short-circuit, thermal, output DC, RF protection
• Variable-speed twin fan back-to-front cooling
• Twist-lockand binding post output connectors
• LED indicators for metering, status, and operating mode
• Variable sensitivity selector

Specifications

NO. OF CHANNELS 2
OUTPUT POWER PER CHANNEL

8: 400W
4: 600W
8 BRIDGED: 1200W

THD AT RATED POWER <1%
DAMPING FACTOR >300
SIGNAL TO NOISE RATIO (20HZ ~ 20KHZ) 101dB
OUTPUT CIRCUITRY

AB
FREQUENCY RESPONSE
20Hz~20kHz, 0.5dB

INPUT CONNECTORS EACH CHANNEL XLR with link
OUTPUT CONNECTORS EACH CHANNEL
Twist-lock connector and binding post

AMPLIFIER AND LOAD PROTECTION
Short circuit, output DC, thermal, RF protection

FRONT PANEL CONTROLS AND INDICATORS

Clip, Protect and Signal LED indicators, 42 detent rotary vol control

REAR PANEL CONTROLS

3 position Slide switch for Mode – Dual, Mono, Bridge. 3 position Slide switch for Sensitivity 0.775V, 1 V and 1.4V.
INPUT POWER
(AS PER BIS IS616:2017 IEC60065:2014/IEC62368-1

700W

DIMENSIONS (WXHXD) MM
483 x 462 x 88

NET WEIGHT 17.5kg
AGENCY APPROVALS
CE, BIS IS616:2017

NOTE: Due to continuous improvements, all specifications are subject to change
